Case Study – pigging system for Soft Drinks ProductiON

Central America

Maximizing Yields and Efficiency: The Impact of HPS Fully Automatic Pigging Systems in Soft Drinks Production Across Central America.

Download the Case Study

Summary

  • HPS designed, supplied and implemented a fully-automatic pigging system for a leading soft drinks manufacturer located in Central America
  • The 3-inch pigging system replaced a blower system, which was inefficient and wasting significant amounts of valuable product
  • Return on Investment (ROI) from the HPS pigging system is outstanding. It is saving the company approximately $31,500 US dollars’ worth of product per pigging run. There is usually one pigging run a day.
  • Product recovery rates rose from approximately 10% using the blower system, to over 99% using the HPS pigging system
  • As well as increasing yields and reducing flush waste, the pigging system for soft drinks production also helps the manufacturer speed up changeovers and minimise water consumption.
  • By reducing manual intervention, the automatic pigging system also enhances safety and improves efficiency
  • By reducing waste, water use, cleaning chemical use and subsequent disposal costs, using pigging also helps towards the company’s environmental sustainability goals.

About the Customer

The HPS client manufactures a number of well-known carbonated soft drinks. The established brand boasts a diverse portfolio of beverages, including soft drinks, water, orange juice, iced tea and sports drinks.

HPS worked with the company at one of its production facilities located in Central America. This particular facility produces and exports concentrates, which are the ingredients of a range of drinks manufactured and created by the company.

Please note out of respect for our client’s confidentiality, we have not named them in this case study.

Project Background

The soft drinks company contacted HPS to discsoft drink production case studyuss a product recovery (pigging) system for a new 3-inch concentrate line. The company’s key objective from pigging was to increase product yield. In addition, it also expected pigging to reduce production down-time and minimise waste and water consumption for rinsing.

Before contacting HPS about a pigging solution, the company had been using a blower system. The performance of the blower system was unsatisfactory. Significant quantities of valuable concentrate were being wasted. The concentrate is an expensive raw ingredient and the blower system was only recovering around 10% of it during changeovers.

The Central American plant had never used pigging. However, some of the company’s other plants had used HPS pigging systems in other facilities and explained the benefits of pigging to Central American staff.

Because there were many different products running through the line, it was important for the soft drinks company to quickly, efficiently and effectively clear them to avoid cross-contamination.

Why the Soft Drinks Company Chose HPS as their Pigging Systems Provider

HPS has a strong reputation as the world’s leading hygienic and sanitary pigging systems specialists and has a proven track record of successful projects which deliver a high return on investment (ROI), rapid payback, and that exceed their client’s expectations. In addition, HPS has worked with a wide variety of companies that manufacture soft drinks, juices and other beverages. These include some of the other company’s processing and bottling plants throughout the world. So, they knew they could rely on HPS to deliver high-quality, effective and reliable product recovery (pigging) solutions.

The Solution

After discussing the company’s objectives and requirements, HPS system designers recommended and supplied a Single-Pig, Fully-Automatic 3-inch Pigging System which includes two launch areas and one receive area.

Because the system is fully automatic, the operator starts the pigging sequence by selecting the appropriate option on an HMI panel. This launches and returns the pig through a series of valves. Special HPS pig-detection technology ensures accurate and reliable pig location and subsequent control by the HMI/PLC.

The equipment also includes a 3-inch HPS process pig for use in hygienic or sanitary applications (which are guaranteed for 18 miles or 30 km of use), plus full engineering drawings, electrical connection diagrams and functional design specification.

HPS provided a full service – from design and supply of a system to implementation, commissioning and ongoing support. When commissioning was complete, HPS engineers ensured employees understood how the system worked and were fully aware on how to properly and safely operate and maintain the equipment.

The Results

The primary aims of the project were to increase yields and reduce product waste on their new 3 inch-line. The pigging system recovers up to 99.5% of product, which is significantly more than the 10% that the blower system was recovering. They have at least one run per day and each pigging run saves the company an estimated $31,500 worth of product. Therefore, the return on investment is significant and the system paid for itself extremely quickly.

The system also reduces effluent and associated disposal costs because nearly all product is recovered and no longer sent to drain. Changeovers are much quicker which improves efficiency of operations. Because the system removes a high percentage of product from the line while cleaning at the same time, there’s no requirement for a lengthy flush out. This reduces water consumption considerably.

Because the company chose an automatic pigging system, safety has been enhanced while automation also minimises the risks of human error through reduced manual intervention. By saving water, resources, and energy, pigging also helps towards their environmental sustainability.

Find out more

The benefits of pigging for beverage production are significant. To improve the efficiency and effectiveness of your beverage processing, please contact your nearest HPS Office.
